Pavo Pico Brushless Whoop Quadcopter Ultra-Light 2S Cinewhoop with HD VTX Bracket, F4 2S 20A AIO Flight Controller, 1102 14000KV Motor, Compatible for O3 VTX for Cruising Indoors Outdoors ELRS

• ＋ Ultra-Light design
• ＋ HD VTX Bracket
• ＋ F4 2S 20A AIO Flight Controller
• ＋ 1102 14000KV Motor
• ＋ Compatible with O3 VTX

note:

• the camera and hd digital vtx (o3 hd digital vtx) are not included in all packages.
• this pavo pico bruhsless whoop only support for the o3 air unit, please make sure the vtx that you have.
• using acetate tape to bind motor wires and prevent them from drooping and interfering with the propeller's rotation.

Items

• pavo pico brushless whoop quadcopter
• color: black
• flight time: 4min
• wheelbase: 80.8mm
• battery: lava 2s 450mah 75c battery
• fc: f4 2s 20a aio fc v1
• props: gf 45mm-3b black propeller
• motor: 1102 | 14000kv red and black (2022)
• weight (no battery): 73.47g
• frame: pavo pico brushless whoop frame
• hd vtx: support o3 air unit (not included), not supported analog vtx
• rx version: pnp
• fpv camera: support o3 camera (not included)

Recommend parts

• motor: 1102 | 14000kv brushless motor
• propeller: gf 45mm 3-blade propeller, gf 45mm 2-blade propeller
• battery: lava 2s 450mah 75c battery
• fc: f4 1s 12a aio fc v3, f4 2s 20a aio fc v1
• frame: pavo pico brushless whoop frame

Package

• 1 * pavo pico brushless whoop quadcopter (without hd digital vtx & camera)
• 1 * lava 2s 450mah 75c battery
• 4 * gf 45mm-3b propellers
• 1 * usb parameter adjustment cable
• 1 * 5.8g copper tube antenna package
• 1 * vtx bracket screw package
• 2 * o3 hd digital vtx antenna mount
• 2 * o3 hd digital vtx mounting bracket
• 1 * o3 lens uv protector
• 1 * o3 lens protective case

• Due to its split design HD VTX mounting bracket, Pavo Pico supports quick installation of O3 HD digital VTX modules and a rubber damper vibration-damping design with GyroFlow stabilization software ensures the output of high-definition videos and smooth HD images
• The battery slot and HD VTX mounting bracket duct height have been reduced to enhance the overall flying experience. DIY battery fixing methods are also supported, making them compatible with batteries of varying sizes and capacities
• The new F4 2S 20A AIO FC V1 upgrades from F4 1S 12A FC V3, weighs only 5.92 grams, and is optimized for HD digital VTX. Its improved computing power, high response speed, and stable flight make it an ideal choice for HD whoops
• Paired with the high-performance Gemfan 45mm propeller, 1102 14000KV brushless motor and PA12 material Frame, this power system achieves superb balance, ensuring powerful lift and stable flight, while also providing precise and responsive control
• The protocol of this drone is the ELRS V3, please use the remote controller that has the same protocol so that they can bind together
